Standard | JIS G3141,DIN1623,EN10130 |
Thickness | 0.15-6.0mm(Aluminum sheet) 6.0-25.0mm(Aluminum plate) |
Temper | H12, H22, H32, H14, H24, H34, H16, H26, H36, H18, H28, H38, H19,
H25, H27,H111, H112,H241, H332, etc. |
Surface Treatment | Mill Finished, Anodized, Embossed, PVC Coated, etc |
Alloy | Application field |
1xxx | 1050 | Insulation, food industry, decoration, lamp, traffic signs, etc. |
1060 | Fan blade, Lamps and lanterns, Capacitor shell, Auto parts, Welding
parts. |
1070 | Capacitor, Rear panel of vehicle refrigerator, charging point, heat
sink, etc |
1100 | Cooker, building material, printing, heat exchanger, bottle cap,
etc |
2xxx | 2A12 | Aircraft structures, rivets, aviation, machinery, missile
components, the card wheel hub, propeller components, aerospace
parts, car parts, and various other structural parts. |
2024 |
3xxx | 3003 | Aluminum curtain wall panel, aluminum Ceiling, Electric cooker
bottom, TV LCD backboard, storage tank, curtain wall, building
construction panel heat sink, billboard. Industrial floor, air
conditioning, refrigerators radiators, Make-up board, Prefabricated
house, etc. |
3004 |
3005 |
3105 |
5xxx | 5052 | Marine and transportation material, railway carriage's inner and
outer cabinet, oil and chemical industry storage device, equipment
and medical device panel, etc. |
5005 | Marine applications, bodies of boats, buses, trucks and trailers.
Curtain wall panel. |
5086 | Ship board, deck, bottom and edge panel, etc. |
5083 | Tanker, oil storage tank, drilling platform, ship board, deck,
bottom, welded parts and edge panel, railway carriage's board,
automotive and aircraft panel, cooling device and automotive
molding, etc. |
5182 | Tanker body, marine facilities, pressure container, transportation,
etc. |
5454 |
5754 |
6xxx | 6061 | Railway inside and outside parts, board and bed plate. Industry
molding
Highly stressed applications include Roofing construction,
transportation, and marine as well as mould. |
6083 |
6082 |
6063 | Auto parts, architectural fabrication, window and door frames,
aluminum furniture, electronic components as well as various
consumer durable products. |
7xxx | 7005 | Truss, rod/bar and the container in transportation vehicles;
Large-sized heat exchangers. |
7050 | Molding (bottles) mode, ultrasonic plastic welding mold, golf head,
shoe mold, paper and plastic molding, foam molding, lost wax mold,
templates, fixtures, machinery and equipment. |
7075 | The aerospace industry, military industry, electronics, etc. |
